Translate Arrays

Build one small box, then reuse it through linear, planar, and volumetric translation tools. The goal is not just duplication, but understanding how each array tool asks for a different measurement and span.

Use this lesson when you need evenly repeated masses such as studs, pavers, shelving blocks, or voxel-like layout studies.

Octodraw UI showing a linear row, a planar grid, and a volumetric cluster of repeated boxes — Generated from a running desktop app through MCP capture. One frame shows the three translation-array families side by side.

Buttons used in this lesson

Use the exact button icon and label shown here when following the tutorial steps.
